Double Heads Keg Filler
Counter pressure filling minimizes beer foam and loss
Integrated keg washing, disinfection and filling system
High-efficiency dual-head simultaneous filling
PLC touchscreen control for one-click operation
Full CE certification for global export compliance
Food-grade 304/316L stainless steel construction
SPECIFICATION | BEER KEG FILLER | |||||
1 | Size:W*L*H | 0.60X0.96X1.57M | ||||
2 | Weight | 102KG | ||||
3 | Packing Size （L*W*H) | 0.75X1.05X1.75M | ||||
4 | Gross Weight | 192KG | ||||
5 | Capacity | 100-120pcs/h(30L),60-80pcs/h(50L) | ||||
6 | Power | Single Phase 110V-240V 50/60Hz is default | ||||
7 | Power consumption | 200W | ||||
8 | Main Material | SUS304 | ||||
9 | Time setting way | Siemens PLC 200 Smart | ||||
10 | Connect type | 1.5" Tri-clamp | ||||
11 | Spear type | A | S | D | G | |
12 | Keg type | EURO DIN AMERICAN 20L-60Lkeg | ||||
13 | With flow meter or not | Yes | ||||
14 | Brand of flow meter | Germany Burkert or IFM | ||||
15 | Filling working procedure | Pressing→ CO2 Spare Pressing→ Filling until arrive at setting parameter→Stop | ||||
