Single Heads Canning

1

Size:W*L*H

1.20x 0.80x1.80M

2

Weight

200KG

3

Packing Size （L*W*H)

1.35x0.95x2.00M

4

Gross Weight

350KG

5

Capacity

800-1000PCS|2 STATION

6

Power

Single Phase   110V-240VAC 50/60Hz is default

7

Power consumption

900W

8

Main Material

AISI304, Aluminum   Alloy and POM

9

Beer Source   Requirement

Temperature: 30.2 -   32F (-1 to 0C)
Carbonation: 2.4 to 2.7 volumes CO2 (4.6 to 5.2 g/L CO2)
Pressure：22psi（0.15MPa）
Connection: 1.5" Tri-clamp

10

CO2 Regulator

58-65 psi（0.4MPa-0.45Mpa） from plant   system connected to canning system with 10mm OD barbed fitting
3/8“：58-65 psi(0.4MPa-0.45Mpa)

11

Air Regulator

87-102 psi（0.6MPa-0.7Mpa） from plant   system connected to canning system with 10mm OD barbed fitting
3/8“：87-102 psi（0.6MPa-0.7Mpa）

12

Time setting way

Capacitive touch   screen F110

13

Seamer

Cemented Carbide
Panasonic Motor

14

Dissolved Oxygen

≤20ppb

15

Can type

Flash Boy FBCS1-1 can   be configured for nearly all standard can sizes! Change over between   different can dimensions is a snap, requiring only a few simple tools and   less than 30 minutes.

16

Rinse function

3S/pc（unadjustable）

17

Spray function

2S/pc（adjustable）
